Allen Bradley 5069-L310ERM CompactLogix 5380 Controller Module

Description

The Allen-Bradley 5069-L310ERM is a CompactLogix 5380 controller module designed for high-performance industrial applications.
Key Features
Controller Type: CompactLogix 5380
Memory: 1 Megabyte
Ethernet/IP Nodes: Supports up to 24 nodes
Communication Ports:
2 Ethernet/IP Ports (10 Mbps, 100 Mbps, 1 Gbps)
1 Type B 2.0 Full-Speed USB Port
I/O Capacity: Supports up to 8 I/O modules
Motion Axes: Supports up to 4 axes of motion control
Topology Support: Device Level Ring (DLR), Star, and Linear topologies
Technical Specifications
Model Number: 5069-L310ERM
Dimensions: 5.67 x 3.86 x 5.39 inches (144 x 98 x 137 mm)
Weight: Approximately 1.693 lbs (0.768 kg)
Operating Temperature: 32 to 140°F (0 to 60°C)
Storage Temperature: -40 to 185°F (-40 to 85°C)
Power Requirements: 18 to 32 Volts DC, maximum current 450 mA
Applications
Manufacturing: Enhances automation and control processes.
Food & Beverage: Ensures precise control in production lines.
Life Sciences: Manages complex laboratory and production environments.
Oil & Gas: Controls and monitors extraction and processing operations.
