Bently Nevada 3300/50 Tachomete

Description

Description
The 3300/50 Tachometer is designed to continuously measure the rotational speed of shafts, rotational acceleration, or provide an output for zero-speed indication. It offers a proportional voltage or current output via the rear terminal strip and features relay contacts for Alert status, enabling integration with external annunciator panels for alerting purposes.
Physical Specifications
Space Requirements:Occupies one rack position (any position except 1 and 2, which are reserved for the Power Supply and System Monitor, respectively).
Weight:1 kg (2.2 lbs.)
Model Configuration: 3300/50-AXX-BXX-CXX-DXX
Option
Description
A: Tachometer Type Option
0 1 Dual Setpoint Tachometer 0 2 Zero Speed Tachometer 0 3 Rotor Acceleration Tachometer
B: Alert Relay Option
0 0 No Relays 0 1 Epoxy-sealed 0 2 Hermetically-sealed 0 4
