Description
Allen-Bradley Input Module 1756-HYD02 – Industrial Automation
High-performance hydraulic motion control seamlessly integrated into the ControlLogix platform.
| Brand | Allen-Bradley |
| Model | 1756-HYD02 |
| Voltage | 24V DC |
| Country of Origin | United States |
| Weight | 0.45 kg |
| Dimensions | 4.8 x 3.2 x 1.8 in |
| Warranty | 2 years |
| Certifications | CE, UL, CSA, ATEX (with barriers) |
| SKU / MPN | 1756-HYD02 |
| What’s in the box | 1 x 1756-HYD02 hydraulic motion module, 1 x mating connector, 1 CD with documentation |
| Axes | 2 servo-hydraulic axes |
| Control Type | Position, velocity, force |
| Update Rate | 250 ?s (fast axis) |
| Feedback | SSI, analog (resolver optional) |
| Power Dissipation | 6.5 W |
| Communication | ControlLogix backplane (1756 chassis) |
Key benefits: Precise multi-axis control, easy programming with RSLogix 5000, robust for harsh environments.
Typical applications: Injection molding machines, hydraulic presses, test stands, material handling.
Order number: Allen-Bradley Input Module 1756-HYD02 – Industrial Automation
Lifecycle: Active
Documentation: Installation instructions, user manual, application notes available at rockwellautomation.com
