Description
Reliable, high-resolution feedback for precise motion control in industrial automation.
| Brand | SICK |
| Model | DBS50E-S5EK00500 |
| Voltage | 10-30 V DC |
| Country of Origin | Germany |
| Weight | 0.3 kg |
| Dimensions | 50 mm diameter x 50 mm length |
| Warranty | 6 months |
| Certifications | CE, UL, RoHS |
| SKU/MPN | DBS50E-S5EK00500 |
| In the Box | 1x SICK DBS50E-S5EK00500 encoder, 1x mounting kit, 1x manual |
| Resolution | 5000 pulses per revolution |
| Output Type | HTL (Push-Pull) |
| Shaft Type | Solid shaft, 6 mm |
| Protection Class | IP65 |
| Operating Temperature | -20°C to +85°C |
| Max Speed | 6000 rpm |
Key benefits: High accuracy, robust design, easy installation, long service life.
Typical applications: Conveyor systems, packaging machinery, motor feedback, robotics.
Lifecycle: Active
Kevin H. –
Arrived in perfect condition. Ran diagnostics, all outputs nominal.
