Description
Precise pressure control with low power consumption and compact design.
| Brand | SMC |
| Model | ITV1050-012N |
| Voltage | 24 VDC |
| Country of Origin | Japan |
| Weight | 0.3 kg |
| Dimensions | 100 mm x 50 mm x 40 mm |
| Warranty | 6 months |
| Certifications | CE, RoHS |
| SKU/MPN | ITV1050-012N |
| In the Box | 1x ITV1050-012N regulator, 1x instruction manual |
| Input Signal | 0-10 VDC or 4-20 mA |
| Output Pressure Range | 0.01 to 0.9 MPa |
| Max Flow Rate | 1500 L/min (ANR) |
| Port Size | 1/8 inch NPT |
| Enclosure Rating | IP65 |
| Operating Temperature | -10 to 50 °C |
Key benefits: High accuracy, energy efficient, easy installation, robust construction.
Typical applications: Pneumatic automation, robotics, packaging machinery.
Lifecycle: Active
